Emerson EK liquid line filter drier EK-165S, PCN: 047618.

The EK Liquid Line filter drier is a premium compacted bead filter drier with a 20 micron outlet pad for maximum filtration. The EK is a premium universal replacement liquid line filter drier for CFC, HCFC and HFC refrigerants including R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, and R-507.

Features

• Filtration first for more effective use of surface area of desiccant

• High moisture and acid removal capacity

• Solid copper connections

• Corrosion resistant epoxy powder paint finish

• Approved for POE oils with Copeland™ compressors

• Shock resistant steel shell construction

Specifications

• Desiccant blend - optimized for high water capacity and acid capacity

• Filtration: 20 microns

• Maximum working pressure: 680 psig

• UL/CUL file number: SA 3124
