We sell SICK compact photoelectric sensor WT24-2B210, small photoelectric sensor WL12L-2B520, displacement measurement sensor OD85-20T1, long range distance sensor DT500-A111.

Photoelectric sensors

The wide selection of photoelectric sensors from SICK ensures that numerous automation engineering applications around the world can be implemented both effectively and efficiently. Photoelectric sensors from SICK are available as standard in a wide range of designs and materials. Thanks to the use of SIRIC®, SICK’s very own ASIC, combined with modern optical technologies, they offer the highest in operational safety, regardless of any on-site interference. Additional sensor information via IO-Link helps to cut the complexity of modern production processes.

Distance sensors

SICK has a wide range of optic and ultrasonic solutions that measure from sub-microns to kilometers. They solve measuring, detecting and positioning applications using triangulation and time-of-flight modes. Sensors using triangulation are ideal for short-range, highly precise measurement. They can inspect miniature parts, thickness and shape, etc. Time-of-flight sensors work at longer distances, are not influenced by reflectivity or ambient light − perfect for positioning AS/RS, rail cars and gantry cranes.

Compact photoelectric sensor WT24-2B210

Sensor/ detection principle: Photoelectric proximity sensor, Background suppression

Dimensions (W x H x D): 27 mm x 87.5 mm x 65 mm

Housing design (light emission): Rectangular

Light source: LED

Adjustment: Potentiometer

Small photoelectric sensor WL12L-2B520

Sensor/ detection principle: Photoelectric retro-reflective sensor, autocollimation

Dimensions (W x H x D): 15 mm x 49 mm x 41.5 mm

Housing design (light emission): Rectangular

Special applications: Detecting small objects, Detection of objects moving at high speeds

Special features: Focusable from 150 mm to 450 mm

Displacement measurement sensor OD85-20T1

System part: Sensor head

Housing material: Metal (Aluminum)

Window material:Glass

Indication: LEDs, 1.4'' color display on evaluation unit

Weight: 250 g

Dimensions (W x H x D): 25.9 mm x 71.5 mm x 53.2 mm

Enclosure rating: IP67

Protection class: III

Long range distance sensor DT500-A111

Supply voltage Vs:

DC 10 V ... 30 V, reverse polarity protected

UV ≥ DC 24 V for devices with heating

Housing material: Metal (Aluminum die cast)

Window material: Glass

Weight: 1,000 g

Dimensions (W x H x D): 69 mm x 50 mm x 153 mm

Enclosure rating: IP65

Protection class: II
