Ideally equipped for industrial and building thermography: The testo 875-1i thermal imager means even the smallest temperature differences can be seen with a thermal sensitivity of < 50 mK.

The testo 875-1i infrared camera’s technical features

The testo 875-1i thermal imager is characterised by its intuitive operation, excellent thermal sensitivity and built-in digital camera.

· Built-in digital camera: Recording real images in parallel to each thermal image makes documentation and assignment easier.

· Resolution and image quality: Detector size 160 × 120 pixels = 19 200 temperature measuring points. SuperResolution Technology enables you to take image quality right up to the next level of 320 × 240 pixels in next to no time. Four times as many readings and a geometric resolution that has been improved by a factor of 1.6 mean you get even more detail and even greater reliability with thermographic measurements.

· Thermal sensitivity < 50 mK: Thanks to a temperature resolution of < 50 mK, even the smallest temperature differences can be seen.

· High-quality 32° × 23° lens: The lens with its manual focusing enables a wide field of view and an ideal overview of the temperature distribution, along with precise focusing on the object being measured.

· Automatic hot/cold spot detection: Critical temperature conditions are directly displayed during thermography.

· Solar mode: The solar radiation value can be input into the thermal imager and stored with each thermal image.

· Pro software for image evaluation on the PC included. You can also choose to save the thermal images as JPEGs. Find out more about the software.

· Measuring range: -30 to +350 °C.

Applications

Preventive maintenance
Detecting structural defects and ensuring construction quality
Easy checking of heating systems and installations
Localize pipe ruptures
Locating leaks in flat roofs
More reliability in quality assurance and production monitoring
Research and development
